Deuod Sic Schottky

Mae deuod SiC Schottky yn fath o lled-ddargludydd perfformiad uchel
dyfais, sydd â manteision foltedd agor isel, uchel
newid cyflymder, perfformiad tymheredd uchel, ac ati, ac yn
a ddefnyddir yn eang mewn cyflenwad pŵer, gyriant, gwrthdröydd, trydan
cerbyd a meysydd eraill. Mae deuodau SiC yn chwarae a
rôl gynyddol bwysig ym maes electroneg pŵer
am eu perfformiad rhagorol a dibynadwyedd, darparu
atebion mwy effeithlon a dibynadwy ar gyfer amrywiaeth o gymwysiadau pŵer uchel.

Anfon ymchwiliad

Disgrifiad

Mae'r deuod Schottky yn cynnwys lled-ddargludyddion metel a math N,
dim haen lled-ddargludyddion P-math, fel arfer yn perfformio'n dda iawn yn
ceisiadau newid cyflymder uchel, amser adfer gwrthdro yn iawn
byr, ac fe'i defnyddir yn eang mewn gostyngiad foltedd isel amledd uchel
senarios, megis trosi pŵer, cywiro cylched, ac ati.

Rhan Rhif.	VRRM (V)	IF(A)	IFSM(A)	Math VF(V).	IR(μA)teip.	Pecyn
WSRSIC006065NPC	650	6	50	1.38	1	I-220-2L
WSRSIC008065NPC	650	8	65	1.38	1.2	I-220-2L
WSRSIC010065NPC	650	10	75	1.38	1.5	I-220-2L
WSRSIC015065NPC	650	15	95	1.38	5	I-220-2L
WSRSIC004065NPD	650	4	30	1.38	0.8	DFN5 * 6
WSRSIC006065NPD	650	6	40	1.38	1	DFN5 * 6
WSRSIC008065NPD	650	8	45	1.38	1.2	DFN5 * 6
WSRSIC006065NPE	650	6	40	1.38	1	DFN8 *8-4L
WSRSIC004065NPF	650	4	30	1.38	0.8	I-220F-2L
WSRSIC006065NPF	650	6	40	1.38	1	I-220F-2L
WSRSIC008065NPF	650	8	50	1.38	1.2	I-220F-2L
WSRSIC010065NPF	650	10	70	1.38	1.5	I-220F-2L
WSRSIC006065NNI	650	6	40	1.38	1	I-220ISO-2L
WSRSIC008065NNI	650	8	50	1.38	1.2	I-220ISO-2L
WSRSIC010065NNI	650	10	70	1.38	1.5	I-220ISO-2L
WSRSIC020065NNI	650	20	130	1.32	3	I-220ISO-2L
WSRSIC005120NNI	1200	5	43	1.4	1	I-220ISO-2L
WSRSIC010120NNI	1200	10	95	1.4	1	I-220ISO-2L
WSRSIC010120NP4	1200	10	95	1.4	5	I-247-2L
WSRSIC020120NP4	1200	20	160	1.4	10	I-247-2L
WSRSIC040120NP4	1200	40	325	1.4	15	I-247-2L
WSRSIC020065NP4	650	20	170	1.32	3	I-247-2L
WSRSIC020065NP8	650	20(10*2)	140(70*2)	1.38	1.5	I-247-3L
WSRSIC020120NP8	1200	20(10*2)	180(90*2)	1.4	5	I-247-3L
WSRSIC030120NP8	1200	30(15*2)	270(135*2)	1.43	8	I-247-3L
WSRSIC040120NP8	1200	40(20*2)	320(160*2)	1.4	10	I-247-3L
WSRSIC004065NPO	650	4	30	1.38	0.8	I-252-2L
WSRSIC006065NPO	650	6	40	1.38	1	I-252-2L
WSRSIC008065NPO	650	8	50	1.38	1.2	I-252-2L
WSRSIC002120NPO	1200	2	18	1.36	1	I-252-2L
WSRSIC004120NPO	1200	4	30	1.36	1.5	I-252-2L
WSRSIC005120NPO	1200	5	43	1.38	2	I-252-2L
WSRSIC010065NPM	650	10	80	1.38	1.5	I-263-2L
WSRSIC020065NPM	650	20	130	1.32	2	I-263-2L
WSRSIC010120NPM	1200	10	95	1.4	5	I-263-2L
WSRSIC020065NPL	650	20	130	1.32	3	I-3PF-3L
WSRSIC010065NNI-AT	650	10	84	1.38	1	TO{0}}ISO-2L(AUTO)
WSRSIC020120NP% 7b{1}}AT	1200	20	180	1.4	3	I247-2L(AUTO)
WSRSIC020065NP4-AT	650	20	180	1.32	1	I247-2L(AUTO)
WSRSIC020065NP% 7b{1}}AT	650	20(10*2)	150(75*2)	1.38	1	I247-3L(AUTO)
WSRSIC020120NP% 7b{1}}AT	1200	20(10*2)	190(95*2)	1.4	3	I247-3L(AUTO)
WSRSIC030120NP8-AT	1200	30(15*2)	280(140*2)	1.43	3	I247-3L(AUTO)
WSRSIC040120NP% 7b{1}}AT	1200	40(20*2)	340(170*2)	1.4	3	I247-3L(AUTO)
WSRSIC010065NPO	650	10	70	1.38	1.5	I-252-2L
WSRSIC020065NPC	650	20	152	1.38	6	I-220-2L
WSRSIC008065NPE	650	8	45	1.38	1.2	DFN8 *8-4L
WSRSIC060120NP4	1200	60	340	1.4	25	I-247-2L
WSRSIC030065NPS	650	30	220	1.38	2	I-247-3L
WSRSIC040065NPS	650	40	290	1.38	4	I-247-3L
WSRSIC010120NPO	1200	10	95	1.4	5	I-252-2L
WSRSIC010120NPCC	1200	10	95	1.4	10	SMC
WSRSIC030065NPC	650	30	220	1.38	2	I-220-2L
WSRSIC004065NPC	650	4	30	1.38	0.8	I-220-2L
WSRSIC030120NP4	1200	30	220	1.4	13	I-247-2L
WSRSIC010120NP8	1200	10(5*2)	43	1.4	1	I-247-3L
